5 Custom-made single-temperature wine cabinet - steel frame with brushed fir wood fintion - 810 Bottles - Storage and présentation shelves in brushed fir wood

Ma Cave à Vin CUSTOM
Ref. : ACI-SPE147

Temperature number : 5
Range of adjustment : Adjustable from 6 to 18 ° C
Capacity of the model : 810 bottles
Level of range : Deluxe product excellence
Model colour : Steel and wood
Dimensions : H2380*W7326*D750 mm
Installation temperature min / max : 16°C / 32°C

Description générale

Technical data

Price on demand

Your product's features :

Water pressure limiter :

To be defined

Extension tube option :

To be defined

Wine Supervisor kit :

To be defined

Share this product

Your product's options:

1 Water pressure limiter

Hide the option

Without limiter kit

Incompatible avec l'option

Without limiter kit Humidifier water inlet pressure must not exceed 2.8 bar

Secure connection kit for humidifier

Incompatible avec l'option

Secure connection kit for humidifier Included : 10m 1/4" polyethylene flexible tubing, 1x overflow safety valve, 1x isolation valve 1/4" 1/4", 1x pressure limiter valve 1/4", 3x 1/4" JG - 3/4" F connection, 1x Y 1/4" 1/4" 1/4"

2 Extension tube option

See the option

Without tube extension

Incompatible avec l'option

Without tube extension

With 20 meter extension tube

Incompatible avec l'option

With 20 meter extension tube

3 Wine Supervisor kit

See the option

Remote control

Incompatible avec l'option

Remote controlThe air conditionner is equipped with a remote control enabling to consult the cellar constants and to modify the settings. The scope of the remote control depends on the number of walls and thickness. Around 100m on open field

Modbus connection to home automation

Synchronization between the air conditionner and your home automation or the supervision of your store via a Modbus communication protocol. Includes a wireless router to radio frequency RS485 and a 230V/mini-USB power supply.

Incompatible avec l'option

Modbus connection to home automationSynchronization between the air conditionner and your home automation or the supervision of your store via a Modbus communication protocol. Includes a wireless router to radio frequency RS485 and a 230V/mini-USB power supply.

Mobile App access V3

A dedicated mobile application enables you to monitor your wine cellar whereever you are : remote control of the air conditionner settings, constants records, real-time alerts, reproduction of natural cellars profiles

Incompatible avec l'option

Mobile App access V3A dedicated mobile application enables you to monitor your wine cellar whereever you are : remote control of the air conditionner settings, constants records, real-time alerts, reproduction of natural cellars profiles

Share this product

Technical data

General features :

Capacity of the model :

810 bottles

Installation :

Built-it models with conditions

Level of range :

Deluxe product excellence

Door version :

Glass (double glazing UV)

Model colour :

Steel and wood

Installation temperature min / max :

16°C / 32°C

Warranty :

2 years parts, labour and travel

Spare parts availability :

5 years

Equipment :

Lock :

Yes

Handle :

Yes

Adaptable interior:

Alarm :

Yes

Lighting :

Switch: on / off:

Yes

Accessories included :

15 Wooden storing shelves
15

Regulation :

Temperature number :

Range of adjustment :

Adjustable from 6 to 18 ° c

Setting :

Technologies :

Heat production :

Winter function :

Nature of the side walls :

Brushed heat-treated spruce with clear varnish

Type of back wall :

Brushed heat-treated spruce with clear varnish

Type of cladding:

Brushed heat-treated spruce with clear varnish

Type of insulation :

Polyurethane foam

Type of gas :

R290a

Electrical power (w) :

3520

3520 W

Type of gas :

R290a

Dimensions :

H2380*W7326*D750 mm

Net weight :

2027 kg

Packaging dimensions :

H2400*W7500*D800 mm

Gross weight :

2315 kg

Volume :

14.4 m³

Origin of manufacture:

France
